Claim Detail

supporting-image

Image shows an RV exterior water-heater/service compartment open on the sidewall. - **Visible components:** Black plastic exterior access door, hinges, latch area, circular door vent/port, inner water heater assembly with metal exhaust/vent tube, fan/grille, wiring, screws, and warning label. - **Labels/text:** Raised **“Suburban”** branding on door; **“HOT”** molded near circular opening. Appliance warning label present but not readable. - **Visible damage/condition:** Door and lower/side edge

Human interpretation • confidence 0.00

supporting-image

Close-up photo of an RV appliance data/specification label inside a compartment, partially obscured and rotated. No visible physical damage is shown. Visible components: - Silver/gray manufacturer rating label/data plate - Black mounting frame/panel - Phillips screws/fasteners - Adjacent gray/white appliance housing edge Readable label/spec text includes: - “ST42” - “5381” - “42,000 BTU/hr” - “#63 DMS (.0370”)” - “14” W.C. (3.48 kPa)” max gas inlet - “10.5” W.C. (2.61 kPa)” min gas inlet - “1.

Human interpretation • confidence 0.00

supporting-image

Claim line 1 image shows a close-up of an RV appliance/compartment frame area with safety labels and wiring visible. A small black metal mounting tab/bracket on the inner frame appears bent/torn or broken away, with chipped paint and exposed/rusted metal around the break and a small hole in the tab. Nearby components include a black vertical metal frame/trim, a lower screw head, yellow/green wiring, and warning labels for appliance/heater operation. Visible label text includes “WARNING / AVERTIS

Human interpretation • confidence 0.00

supporting-image

Photo shows exterior side window/glass area of a K-Z RV stock unit. No clear visible damage or repair defect is identifiable in this image. Visible components/context: - Tinted RV window/glass with black frame/trim. - Interior screen visible through glass. - Partial circular exterior decal at right, appears to read “KING…” and “STA… / EST…” - Green round sticker marked “24.” - Unit identification label on glass reads: “2025 CONNECT 261RB / VIN:07753 Stock # 11055.” Claim linkage: - Image appea

Human interpretation • confidence 0.00

supporting-image

Claim line linkage: File name indicates LINE 1; image likely supports appliance identification for claim line 1. Visible components: Close-up of an RV appliance cabinet/door area with black door frame, hinge hardware, screws, and gray appliance side panel. Visible damage/condition: No clear physical damage shown. Minor dust/scuffs around screws/edge area; screw heads appear intact though slightly worn/marked. Labels/text visible: - Safety label: “FOR YOUR SAFETY: DO NOT STORE OR USE GASOLINE

Human interpretation • confidence 0.00

supporting-image

Claim line 1 image shows the exterior access door/panel for a Suburban RV water heater on the sidewall. - **Visible components:** Black Suburban water heater cover, round exhaust/inspection opening with metal burner screen, lower louvered vent slots, small rectangular latch, mounting screws/rivets. - **Visible text/labels:** Embossed “Suburban,” “HOT,” and faint warning text “DO NOT BLOCK ANY OPENINGS.” - **Condition/damage observed:** No clear cracked or broken panel visible. Some dust/road gr

Human interpretation • confidence 0.00

supporting-image

Warranty claim screenshot showing an RV parts/repair catalog tree. - Unit/context visible: **C261RB (13)** with category folders. - Selected area: **Appliances → Water Heater**. - Listed water heater parts: - **164594** – `HEATER,WATER,DEMAND,42,000 BTU,SUBURBAN,(THERMOSTAT IS 505416)` - **164595** – `DOOR,WATER HEATER,DEMAND,42,000,BTU,BLACK` - Other visible appliance categories: Air Conditioner, Antenna, Audio/Video, Fireplace, Furnace, Microwave, Oven/Cooktop, Rangehood, Refrigerator, Sa

Human interpretation • confidence 0.00

supporting-image

Screenshot of an email reply from K-Z RV parts advisor Karin Jarvis to Tri-Am Tennessee Parts. - Visible damage: none shown; this is a document/email screenshot, not a physical part photo. - Parts/components referenced: water heater door latches. - Key text: “Reply from vendor — DOOR LATCHES FOR WATER HEATERS DOORS NOT SOLD SEPARATELY.” - Sender/details: Karin Jarvis <kjarvis@k-z-rv.com>, K-Z Recreational Vehicles; sent Fri 3/14/2025 1:32 PM. - Repair/claim context: vendor indicates the request

Human interpretation • confidence 0.00
